STARBLOCK

12 / 20

12 DOUBLERECESS
USE : ALL WOODS, PLYWOODS, MELAMINE COVERED
WOOD, MDF, ETC...
COUNTERSUNK SCREWS
WHITE ZINC-PLATED STEEL
USING THE SQUARE
BIT, THE SCREW IS
HELD IN PLACE .
COMPATIBLE WITH BITS
WOOD / MDF
DOUBLE
RECESS
SQUARE PHILLIPS FLAT POZIDRIV
X1 X1 X 5
SIZE THREAD QTY REF GENCOD QTY REF GENCOD QTY REF GENCOD
4x16 TOTAL 500 477811 3154551531272 500 477830 3154551531371 200 478364 3154551536574
4x20 TOTAL 500 477812 3154551531289 500 477831 3154551531388 200 478365 3154551536581
4x25 TOTAL 500 477813 3154551531296 500 477832 3154551531395 200 478366 3154551536598
4x30 PARTIEL 18 500 477551 3154551527398 500 477697 3154551529774 200 478367 3154551536604
4x35 PARTIEL 22 500 477552 3154551527404 500 477698 3154551529781 200 478368 3154551536611
4x40 PARTIEL 25 500 477553 3154551527411 500 477699 3154551529798 150 478369 3154551536628
4x50 PARTIEL 30 250 477554 3154551527428 250 477700 3154551529804 100 478370 3154551536635
4x60 PARTIEL 35 250 477814 3154551531302 250 477833 3154551531401 100 478371 3154551536642
4,5x30 TOTAL 500 477815 3154551531319 500 477834 3154551531418 200 478372 3154551536659
4,5x40 PARTIEL 25 500 477555 3154551527435 500 477701 3154551529828 100 478373 3154551536666
4,5x50 PARTIEL 30 250 477556 3154551527442 250 477702 3154551529835 100 478374 3154551536673
4,5x60 PARTIEL 35 250 477817 3154551531333 200 477835 3154551531425 100 478375 3154551536680
5x40 PARTIEL 25 500 477818 3154551531340 300 477836 3154551531432 100 478376 3154551536697
5x50 PARTIEL 30 250 477557 3154551527459 250 477703 3154551529842 80 478377 3154551536703
5x60 PARTIEL 35 250 477558 3154551527466 200 477704 3154551529859 80 478378 3154551536710
5x70 PARTIEL 45 250 477559 3154551527473 200 477705 3154551529866 50 478379 3154551536727
5x80 PARTIEL 50 250 477560 3154551527480 200 477706 3154551529873 50 478380 3154551536734
6x50 PARTIEL 25 250 477819 3154551531357 200 477837 3154551531449 50 478381 3154551536741
6x60 PARTIEL 30 200 477561 3154551527497 150 477707 3154551529880 50 478382 3154551536758
6x70 PARTIEL 35 200 477820 3154551531364 150 477838 3154551531456 50 478383 3154551536765
6x80 PARTIEL 45 200 477562 3154551527503 150 477708 3154551529897 50 478384 3154551536772
6x100 PARTIEL 60 200 477563 3154551527510 100 477709 3154551529903 50 478385 3154551536789
6x120 PARTIEL 70 100 477564 3154551527527 100 477710 3154551529910 25 478386 3154551536796
6x140 PARTIEL 70 100 477565 3154551527534 100 477711 3154551529927 25 478387 3154551536802
DIAMETER 4 4.5 5 6
SIZE BIT Sq2 Sq2 Sq2 Sq3
